| Thermalright AXP90-X47 Specifications | |
| Dimension | L94.5 mm x W95 mm x H21 mm |
| Weight (With Fan) | 250g |
| Heat pipes | 6mm heatpipe x 4 units |
| Fin | T = 0.3 mm；Gap=1.6 mm |
| Fin pcs | 54 pcs |
| Copper Base | C1100 Pure Copper nickel plated |
| TL-9015 FAN Spec | |
| Dimension | L92 mm x W92 mm x H15 mm |
| Rated Speed | 2700 RPM±10% (MAX) |
| Noise Level | 22.4 dBA |
| Air Flow | 42.58 CFM (MAX) |
| Air Pressure | 1.33mm H2O (MAX) |
| Ampere | 0.18 A |
| Connector | 4 Pin (PWM Fan connector) |
| Bearing Type | HYDRAULIC Bearing |
